Home /Products/Portable Axle Scales/Portable Wire Truck Axle Scale Digital Balance Touch Screen Indicator Customized OEM ODM Supported Weighing Scales

Portable Wire Truck Axle Scale Digital Balance Touch Screen Indicator Customized OEM ODM Supported Weighing Scales

1 set
MOQ
USD300~600
Price
Portable Wire Truck Axle Scale Digital Balance Touch Screen Indicator Customized OEM ODM Supported Weighing Scales
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Portable Axle Weighing Scale
Type: Axle Scale
Display Type: 100~240V
Model Number: AS002
Use: Weigh The Weight Of The Product
Market: All Over The World
Rated Load: 30t
Basic Infomation
Place of Origin: China
Brand Name: SKYERSCALE
Certification: CE
Model Number: AS002
Payment & Shipping Terms
Packaging Details: Box
Delivery Time: 5-30 working days
Payment Terms: T/T
Supply Ability: 1 Piece/Pieces per Day
Product Description

Portable Wire Truck Axle Scale Digital Balance Touch Screen Indicator Customized OEM ODM Supported Weighing Scales

Configuration Table
Model

Size(A*B*C)

(mm)

Capacity

(Per Weigh Pad)

 Description(Each Pad)
AS002 300*400*35 500/1000/1500Kg

4pcs LoadCell,10m Cable

Capacity:500/1000/1500Kg
400*500*58 1500/2500/3000/Kg

4pcs LoadCell,10m Cable

Capacity:1500/2500/3000Kg
400*500*58 5000Kg

4pcs LoadCell,10m Cable

Capacity:5000Kg
450*700*58 5000/10000/15000Kg

6pcs LoadCell,10m Cable

Capacity:5000/10000/15000Kg
500*900*58 10000/15000/20000/25000Kg

6pcs LoadCell,10m Cable

Capacity:10000/15000/200000Kg



Product Parameters
Rated load:1/2/3/5/6/10/20/30/40T Compensated temp.range(℃): -10~+50
Dynamic error (%F.S): 3 (5~10km/h) Static error (%F.S):0.1~0.3
Static comprehensive error(%F.S): 0.1~0.5 Insulation resistance(MΩ): ≥5000(100VDC)
Rated output(mV/V): 1.0±0.1 Use temp.range(℃): -30~+80
Non-linearity(%F.S): 0.2 Temp.effect on zero(F.S/10℃): 0.03
Error on corners(%F.S): 0.2 Temp.effect on span(F.S/10℃): 0.05
Repeatariy(%F.S): 0.05 Safe overload(%): 120
Zero balance(%F.S): ±1 Ultimate overload(%): 150
Excitation voltage(VDC): 9~15 Net weight(kg): 45
Recommended voltage(V): 10 Defend grade: IP66
Wireless Specification
A/D conversion method Σ-Δ 24bit
Input signal range –19.5mV~19.5mV
Load cell excitation DC 5V
Max. connection number of load cell 1~4
Load cell connection mode 4 wire
Operating temperature -10 °C ~40 °C
Allowable working temperature -40 ° C ~ 70 ° C
Wireless transmission frequency 430MHz to 470MHz
Wireless transmission distance 800 meters (In Open Place)
Features
  • 1):two separate calibration of the weighing platform, with a 10-point amendment to greatly improve the accuracy of the product.
  • 2):The floating zero and zero tracking technology, the complete elimination of zero drift.
  • 3):Figures of the menu operation, simple and clear.

Portable Wire Truck Axle Scale Digital Balance Touch Screen Indicator Customized OEM ODM Supported Weighing Scales 0

Portable Wire Truck Axle Scale Digital Balance Touch Screen Indicator Customized OEM ODM Supported Weighing Scales 1
