High Temperature Resistant Crane Digital Scale

1
MOQ
negotiation
Price
High Temperature Resistant Crane Digital Scale
Features Gallery Product Description Request A Quote
Features
Specifications
Rated Load: 15ton
Display Type: LED And LCD
Power Supply: 220V/50HZ
Type: Crane Scale
Place Of Origin: China
Highlight:

digital crane scale 15T

,

led lcd digital crane scale

Basic Infomation
Place of Origin: China
Brand Name: SKYERSCALE
Certification: CE
Model Number: DH2 series
Payment & Shipping Terms
Packaging Details: carton/wooden box
Delivery Time: 20days
Supply Ability: 2000pcs/m
Product Description

High temperature resistant metallurgical industry digital crane scale 15T

Specifications:



Model Max Cap Min. Weigh Division Total Display Counts
(Kg) (Kg) (Kg) (N)
CS-DH2 -1 1000 10 0.5 2000
CS-DH2 -2 2000 20 0.5 2000
CS-DH2 -3 3000 20 1 3000
CS-DH2-5 5000 40 1 2500
CS-DH2-10 10000 100 2 2000
CS-DH2-15 15000 100 2 2000



Min Distance Between Scale And High Temperature:

1000℃ 1200℃ 1400℃ 1600℃
1.2m 1.5m 1.8m 2.0m

High Temperature Resistant Crane Digital Scale 0



Description:

Capacity: 1t/2t/3t/5t/10/15t

● Ultra- low-power design, circuit board smaller.

● Large capacity battery configuration, longer life.

●Unique intelligent charging protection function, prevention of over- current, over charge phenomenon. The battery life of a stronger, more

Lasting.

● Ultra-bright, low-brightness display, automatic adjustment ( to be set )

● Startup, shutdown, automatic voltage display.

● Good dynamic weighing performance, not because of swaying affect the weighing

● With a wireless remote control for easy operation.

● Cumulative,automatic total, peeled, peeled distance, numerical maintained, showing sub- value choice, any weight correction.

● Overload, underload remind display, low voltage alarm, battery capacity is less than 10 % of the police.Technical Specifications

● Specially designed for metallurgy ,like iron and steel plant.

● Optional wireless communication module, the working carrier frequency is 430MHz ~ 470MHz

ISM band between the open, license-free use,

The current weighing data to within 800m wireless meter or PC display or management.

Accuracy class according to international standard three scales.

Battery charging time of about 70 hours working time

Safe overload 150% F.S

Destruction of overloading 300% F.S

Operating temperature -10 ~ 50 ℃

Environment Humidity <90% R.H

Monitor specifications 5 30mm (1.2〃)LED high brightness displays.

Reading stabilization time <3S

Remote distance <25M



Applications:

1. vehicle lifting

2. Railway terminal, iron and steel metallurgy, energy mines, factories, mines and other enterprises in the field of heavy cargo loading and unloading weighing.



Competitive Advantage:


1. your inquiry and e-mai will be replied within 12 hours.



2. If you need to develop product with your own specification, we have professional engineers to work it out.



3. Never leave customer alone, solve problems with customer together.



4. Customer first, quality first, service first!
