BM6G 100kg ~ 500kg Load Cell ZEMIC Single Point Sensor OIML NETP Force Transducer For Electronic Weighing Bench Scale

1pcs
MOQ
negotiation
Price
BM6G 100kg ~ 500kg Load Cell ZEMIC Single Point Sensor OIML NETP Force Transducer For Electronic Weighing Bench Scale
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Stainless Steel
Theory: Resistance Sensor
Output: Analog Sensor
Usage: Weighing Scale
Rated Load: 100kg
Waterproof Grade: IP68
Highlight:

500kg single point sensor

,

BM6G single point sensor

Basic Infomation
Place of Origin: China
Brand Name: ZEMIC
Certification: OIML
Model Number: BM6G
Payment & Shipping Terms
Packaging Details: carton
Delivery Time: 3-20days
Supply Ability: 100pcs/m
Product Description

BM6G 100kg ~ 500kg load cell ZEMIC single point sensor OIML NETP force transducer for electronic weighing bench scale



Specifications:



Rated Load: 50kg~1000kg Insulation Resistance: ≥5000MΩ
Sensitivity: (2.0±0.1%) mV/V Operating Temp.Range: -30~+70℃
Combined Error: ±0.03% F.S Maximum Safe Over Load: 150%F.S
Creep Error(30min): ±0.03% F.S Ultimate Over Load: 200%F.S
Zero Balance: ±1% F.S Recommend Excitation Vol.: 10~12V DC
Temp. Effect On Zero: ±0.02% F.S/10℃ Maximum Excitation Vol.: 15V DC
Temp. Effect On Span: ±0.02% F.S/10℃ Sealing Class: IP65
Input Resistance: 385±5Ω Element Material: Aluminum
Output Resistance: 353±2Ω Cable: Length=L:3m
Insulation Resistance: ≥5000MΩ Citation:

GB/T7551-2008

/ OIML R60



BM6G 100kg ~ 500kg Load Cell ZEMIC Single Point Sensor OIML NETP Force Transducer For Electronic Weighing Bench Scale 0

Description:



1. Zemic L6G load cells are available in the capacities 50~1000kg .And the customized capacity is available by request.
2. Aliminum construction,making it in all kinds of environments. Silicon adhesive sealed, surface anodized and anti-corrosion.
3. good self-aligning ability, suitable for electronic platform scales,automobile testing facilities,hopper scales and other electronic weighing devices.

BM6G 100kg ~ 500kg Load Cell ZEMIC Single Point Sensor OIML NETP Force Transducer For Electronic Weighing Bench Scale 1BM6G 100kg ~ 500kg Load Cell ZEMIC Single Point Sensor OIML NETP Force Transducer For Electronic Weighing Bench Scale 2





Applications:



Suitable for pricing scales, platform scales and other electronic weighing devices.



Competitive Advantage:



1. Low MOQ: It can meet your promotional business very well.

2. OEM Accepted : We can produce any your design .

3. Good Service : We treat clients as friend.

4. Good Quality :We have strict quality control system .Good reputation in the market.

5. Fast & Cheap Delivery: We have big discount from forwarder.
